LSS100 (PRF Coding)
Depiction of LSS Laser Source Simulator in use
LSS-100, Laser Source Simulator with PRF Coding
Depiction of LSS Laser Source Simulator in useThe AZ Technology LSS-100 Laser Source Simulator generates simulated optical laser signals encoded with PRF codes for operational, testing of seekers on laser-designated weapons. The LSS-100 represents a cost-effective method to perform seeker system operational readiness tests just prior to mission.
Configuration:
- Portable, hand-held, battery powered
- Simulated 1064 nm laser source
- Eye safe LED light source
- Nominal 50 nsec pulse width
- Low pulse-to-pulse time/amplitude jitter
- Encodes all valid PRF values
- Direct input of PRF codes
- Proven compatibility with Hellfire and Hellfire II seekers
The table below lists specifications for the LSS-100 Laser Source Simulator.
Specifications
| Emitter | Type: LED Peak Wavelength: 1050nm ± 50 nm Wavelength Half Width: 70 nm Illumination Angle: ± 15 degrees |
| Power source | Source: Standard 9 volt battery Duration: Continuous Pulse Use ≥ 5 hours |
| Dimensions | 4.0″ x 5.3″ x 1.5″ |
| Operating temperature | 0 to 140 degrees F |
| Effective range | 0 to 10 feet, typically 30 feet |
| Time base accuracy | 1 part-per-million |
| Warranty | 90 days parts and labor |
*The LSS-100 is Export-Controlled as Defined in the International Traffic in Arms Regulations (ITAR).
